Maltodextrin Production Plant

JiangSu Xiandao can provide glucose and maltodextrin production plant which can produce glucose or maltodextrin by hydrolysis of plant enzymes.

Starch → size mixing → the first time liquefaction → high temperature enzyme inactivating → the second time liquefaction → enzyme inactivating and decoloration → filtering → ion exchanging → concentration → spray drying → product

300Kg/h maltodextrin emulsion spray dryer

1. Feed liquid condition
Material name: maltodextrin emulsion
Solid content: 57%
Final water content: ≤5%
Water evaporation: 300Kg/h
Feed liquid temperature: 65-70℃ (take it as 65℃ for design)
Bulk density of the product: 0.553g/ml

2. Process conditions
Atomization method: centrifugal type
Contact method of the droplet and hoot air: parallel flow
Inlet air temperature: self-controlled 190-195℃
Outlet air temperature: self-controlled 81-85℃
Primary model selection: LPG-300 spray dryer group
Air filtering system: high efficiency low, medium and high temperature air filter with high efficiency differential pressure display
Heating system: steam heating+electric heating compensation (full electric heating when there is no steam heating)
Medium circulation system: forced draft fan and induced draft fan open circulation
Material feeding system: adjustable automatic material feeding carried out by screw pump
Dust collection system: cyclone separation+bag dust cleaning
Product capturing and collection system: cold air material dehumidification, cooling and collection
Tower wall temperature adjusting mode: tower wall jacket air cooling
Control system: human-computer interface+PLC process control

The glucose and maltodextrin production plant provided by JiangSu Xiandao is mainly used for glucose and maltodextrin production. We can provide different equipment configuration according to your targeted yield. We can also provide systematical installation and debugging services and operation training afterwards and maintenance service. If you want to learn more about this plant, please contact us.
